Ar234B-2 9./KG 76 (BM+LM) vkz (F1+MT) Yellow M WNr.140173 Shot Down By P-47 & Crashed At Segelsdorf, Germany
February 24, 1945:
Later, At RAE Farnborough Engines Were Removed For Examination On March 21, 1945
 [1469x491] (48K)

Ar234 V5 1./Versuchsverband.Ob.d.L. (GK+IV) vkz (T9+LH) WNr.130005 with Two Jumo-004A-0 Engines & with Skid Undercarriage & TakeOff Trolley
1st Flight December 22, 1943
 [1531x1030] (160K)

Ar234B-2 1.(F)33 vkz (8H+EH) WNr.140489 Named 'Jane I' Watson's Whizzers #202 (USA5) & USN BuAer 121445 & Ar234B-2 9./KG 76 (NB+BQ) vkz (F1+FT) WNr.140343
Named 'Snafu I'
Watson's Whizzers #303
USN BuAer 121446 At Melun Villaroche Airfield, 34Km SouthEast of Paris, France
On June 27, 1945 Prior to
Shipment to USA
 [1526x429] (32K)

Ar234B-1
1./Versuchs.Verb.OKL
ex-Versuchs.Verb.Ob.d.L. &
ex-Sonderkommando Sperling Whose Jet-Propelled Sparrow Emblem Is Still On Nose
(NM+BW) vkz (T9+KH) WNr.140349 with Two Outer
Wing-Mounted Walter Ri202b
(109-500) RATO Units &
Leutnant Mensching on Top of Fuselage Aiding Oberleutnant Werner Muffey Strapping In For Flight
Late 1944
 [1163x570] (51K)

Ar234B-2 V9 (PH+SQ) WNr.130009 Taxiing with Two 300-Liter Fuel Tanks Mounted Under Jumo-004B-1 Jet Engines On ETC503A-1
Bomb Racks
 [586x453] (22K)

Ar234B-2 7./KG 76 vkz (F1+DR) WNr.140312 Captured At Sola Airfield, Stavanger, Norway (USA50) (FE-1010)/(T2-1010) Watson's Whizzers #505 Photo with PV-1b Rear-Vision Periscope Or Shallow Dive BZA-1b Bombsight At Freeman Field, Indiana June 1945
 [724x262] (18K)

Ar234B-2 7./KG 76 vkz (F1+DR) WNr.140312 Captured At Sola Airfield, Stavanger, Norway (USA50) (FE-1010)/(T2-1010) Watson's Whizzers #505 Photo with PV-1b Rear-Vision Periscope Or Shallow Dive BZA-1b Bombsight At Freeman Field, Indiana June 1945
 [727x329] (96K)

Ar234B-2 7./KG 76 vkz (F1+DR) WNr.140312 Captured At Sola Airfield, Stavanger, Norway (USA50) (FE-1010)/(T2-1010) Watson's Whizzers #505 Photo with PV-1b Rear-Vision Periscope Or Shallow Dive BZA-1b Bombsight At Freeman Field, Indiana June 1945
 [750x500] (18K)

Ar234B-2 7./KG 76 vkz (F1+DR) WNr.140312 Captured At Sola Airfield, Stavanger, Norway (USA50) (FE-1010)/(T2-1010) Watson's Whizzers #505 Photo with PV-1b Rear-Vision Periscope Or Shallow Dive BZA-1b Bombsight At Freeman Field, Indiana June 1945
 [900x323] (21K)

Ar234B-2 7./KG 76 vkz (F1+DR) WNr.140312 Captured At Sola Airfield, Stavanger, Norway (USA50) (FE-1010)/(T2-1010) Watson's Whizzers #505 Photo with PV-1b Rear-Vision Periscope Or Shallow Dive BZA-1b Bombsight At Freeman Field, Indiana June 1945
 [1024x683] (60K)

Ar234B-2b Einsatzkommando 1./FAGr.5 vkz (9V+CH) WNr.140493 Captured By RAF & Assigned AirMin 228 At Sola Airfield, Stavanger, Norway 1945
& Was Used For Reconnaissance Over Britain & U-Boat Target Location Over North Sea:
Photo Shows Engine Start By Luftwaffe Crew Under RAF Supervision (Hands on Hips) with 2 Scottish Correspondents(Left) At Sola Airfield, Stavanger, Norway
August 6, 1945
 [591x357] (19K)

Ar234B-2b Einsatzkommando 1./FAGr.5 vkz (9V+CH) WNr.140493 Captured By RAF & Assigned AirMin 228 At Sola Airfield, Stavanger, Norway 1945
& Was Used For Reconnaissance Over Britain & U-Boat Target Location Over North Sea:
Photo Shows Engine Start By Luftwaffe Crew Under RAF Supervision (Hands on Hips) with 2 Scottish Correspondents(Left) At Sola Airfield, Stavanger, Norway
August 6, 1945
 [681x409] (26K)

Ar234B-2b Einsatzkommando 1./FAGr.5 vkz (9V+CH) WNr.140493 Captured By RAF & Assigned AirMin 228 At Sola Airfield, Stavanger, Norway 1945
& Was Used For Reconnaissance Over Britain & U-Boat Target Location Over North Sea:
Photo Shows Engine Start By Luftwaffe Crew Under RAF Supervision (Hands on Hips) with 2 Scottish Correspondents(Left) At Sola Airfield, Stavanger, Norway
August 6, 1945
 [699x499] (28K)

Ar234B-2b Einsatzkommando 1./FAGr.5 vkz (9V+CH) WNr.140493 Captured By RAF & Assigned AirMin 228 At Sola Airfield, Stavanger, Norway 1945
& Was Used For Reconnaissance Over Britain & U-Boat Target Location Over North Sea:
Photo Shows Engine Start By Luftwaffe Crew Under RAF Supervision (Hands on Hips) with 2 Scottish Correspondents(Left) At Sola Airfield, Stavanger, Norway
August 6, 1945
 [748x446] (135K)

Ar234B-2 V9 (PH+SQ) WNr.130009
1st Retractable Tricycle Gear & with Two Jumo-004B-1 Engines with One ETC503A-1 Bomb Rack Under Each Engine, Aircraft Used for Bomb Drop Trials, 1st Flight March 12, 1944
 [1523x465] (50K)

Ar234 V3 A-Prototype (DP+AX) WNr.130003 with Two Jumo-004A-0 Engines & with Skid Undercarriage Taking Off Using Walter Ri202b (109-500) RATO Rockets with Both RATOs Producing 1000Kg Extra Thrust (Extra 60+%) for 30 Seconds
 [567x310] (14K)

Ar234B-2 (S-10) (GM+BJ) WNr.140110 vkz (E2+20) Tested Hs293 Anti-Ship Missile & Hs293 FuG203 Radio Guidance System
At Erprobungsstelle Rechlin
[E.Stelle Rechlin]
(Test Center Rechlin)
Mechanics Preparing for Flight
 [478x196] (15K)

Ar234B-2 (S-10) (GM+BJ) WNr.140110 vkz (E2+20) Tested Hs293 Anti-Ship Missile & Hs293 FuG203 Radio Guidance System
At Erprobungsstelle Rechlin
[E.Stelle Rechlin]
(Test Center Rechlin)
Mechanics Preparing for Flight
 [533x221] (18K)

Ar234B-2 (S-10) (GM+BJ) WNr.140110 vkz (E2+20) Tested Hs293 Anti-Ship Missile & Hs293 FuG203 Radio Guidance System
At Erprobungsstelle Rechlin
[E.Stelle Rechlin]
(Test Center Rechlin)
Mechanics Preparing for Flight
 [600x236] (44K)

Ar234B-2 (S-10) (GM+BJ) WNr.140110 vkz (E2+20) Tested Hs293 Anti-Ship Missile & Hs293 FuG203 Radio Guidance System
At Erprobungsstelle Rechlin
[E.Stelle Rechlin]
(Test Center Rechlin)
Mechanics Preparing for Flight
Rechlin, Germany
From October to December 1944
 [1537x892] (97K)
