Ar234B-2 V9 (PH+SQ) WNr.130009 1st Retractable Tricycle Gear & with
Two Jumo-004B-1 Engines,
Aircraft Used for Bomb
Drop Trials
1st Flight March 12, 1944
 [1497x701] (193K)

Ar234 V13 (PH+SU) WNr.130023 with FM-2b Rear-Vision Periscope & Powered By Four BMW-003A-1 Engines, Test Model for C-3 Flight Test September 6, 1944
 [1126x395] (31K)

Ar234 V13 (PH+SU) WNr.130023 with FM-2b Rear-Vision Periscope & Powered By Four BMW-003A-1 Engines, Test Model for C-3 Flight Test September 6, 1944
 [1449x521] (153K)

Ar234B-2 Einsatzstaffel Lukescha Later, 9./KG 76 vkz (F1+BT) Mechanics Prepare Eins.Staffel Lukesha Commander Hauptmann Diether (Dieter) Lukesch's Plane For Mission From Munster-Handorf Airfield, Germany January 1945
 [800x470] (68K)

Ar234B-2 Einsatzstaffel Lukescha Later, 9./KG 76 vkz (F1+BT) Mechanics Prepare Eins.Staffel Lukesha Commander Hauptmann Diether (Dieter) Lukesch's Plane For Mission From Munster-Handorf Airfield, Germany January 1945
 [1451x843] (172K)

Ar234B-2 (S-16) 8./KG 76 (GM+BP) vkz (F1+BS) WNr.140116 with Two SC50 50Kg Practice Bombs Under Each BMW-003A-1 Engine At Burg, Germany: Later, Crashed On TakeOff January 12, 1944
 [380x216] (13K)

Ar234B-2 (S-16) 8./KG 76 (GM+BP) vkz (F1+BS) WNr.140116 with Two SC50 50Kg Practice Bombs Under Each BMW-003A-1 Engine At Burg, Germany: Later, Crashed On TakeOff January 12, 1944
 [600x271] (59K)

Ar234B-2 (S-16) 8./KG 76 (GM+BP) vkz (F1+BS) WNr.140116 with Two SC50 50Kg Practice Bombs Under Each BMW-003A-1 Engine At Burg, Germany: Later, Crashed On TakeOff January 12, 1944
 [800x453] (84K)

Ar234B-2 (S-16) 8./KG 76 (GM+BP) vkz (F1+BS) WNr.140116 with Two SC50 50Kg Practice Bombs Under Each BMW-003A-1 Engine At Burg, Germany: Later, Crashed On TakeOff January 12, 1944
 [800x361] (86K)

Ar234 V6 (GK+IW) WNr.130006 Undergoing BMW-003A-0 Engine Start with Aid of an External Engine to Spin Turbine Blades At
Alt-Lönnewitz, Brandenburg, Germany March 1944
 [1005x566] (68K)

Ar234B-2b 1./(F)33 vkz (8H+DH) WNr.140476 Captured By RAF & Assigned AirMin 26 (VK877)
At Karup-Grove Airfield,
Denmark 1945
 [800x461] (21K)

Ar234B-2 7./KG 76 vkz (F1+DR) WNr.140312 (USA50)
(FE-1010)/(T2-1010)
Watson's Whizzers #505
Refurbished Without PV-1b
Rear-Vision Periscope
Photo At Wright Field, Dayton, Ohio Fall 1946
 [395x198] (11K)

Ar234B-2 7./KG 76 vkz (F1+DR) WNr.140312 (USA50)
(FE-1010)/(T2-1010)
Watson's Whizzers #505
Refurbished Without PV-1b
Rear-Vision Periscope
Photo At Wright Field, Dayton, Ohio Fall 1946
 [569x371] (21K)

Ar234B-2 1./(F)33 vkz (8H+EH) WNr.140489 Named 'Jane I'
Watson's Whizzers #202 (USA5)
USN BuAer 121445 Naval Test Center, Patuxent River, Maryland
 [617x360] (18K)

Ar234B-2 1./(F)33 vkz (8H+EH) WNr.140489 Named 'Jane I'
Watson's Whizzers #202 (USA5)
USN BuAer 121445 Naval Test Center, Patuxent River, Maryland
 [833x407] (57K)

Ar234B-2a (S-7) (GM+BG) WNr.140107 General Airframe Tests Done By Rechlin Experimental Station As vkz (E2+30):
Later, Captured By RAF
As II./KG 76 (22+07)
RAF AirMin 78 when Found At Schleswig-Holstein,
Germany 1945
 [649x372] (62K)

Ar234B-2a (S-7) (GM+BG) WNr.140107 General Airframe Tests Done By Rechlin Experimental Station As vkz (E2+30):
Later, Captured By RAF
As II./KG 76 (22+07)
RAF AirMin 78 when Found At Schleswig-Holstein,
Germany 1945
 [800x485] (32K)

Ar234B-2a (S-7) (GM+BG) WNr.140107 General Airframe Tests Done By Rechlin Experimental Station As vkz (E2+30):
Later, Captured By RAF
As II./KG 76 (22+07)
RAF AirMin 78 when Found At Schleswig-Holstein,
Germany 1945
 [1024x630] (57K)

Ar234B-2 Abandoned At Neubiberg Airfield, Munich, Germany
May 1945
 [645x337] (55K)

Ar234B-2 Abandoned At Neubiberg Airfield, Munich, Germany
May 1945
 [644x365] (14K)
